AnimalCare Optimice - Model C77200 -Rack For Water Bottles

Recommendations: The Optimice IVC rack has a 100 cage capacity. Typically customers will order 140 cages in order to have enough cages available for cage change out. We also recommend purchasing our Blockparty enrichment cages C79110PBPDF and connecting tubes C79BP050 for some or all of the cages to provide enrichment by increasing cage complexity and living space.

Typical products purchased with this rack are:

• Optimice Standard Cage Bottom: C79110PF
• Optimice/Optirat GenII Standard Bottle and Cap: C79122P
• Optimice Large Capacity Feeder: C40103
• Optimice Standard Cage Top: C79290P
• Optimice Standard Cage Card Holder with Adapter: C79253
• Airflow and Static Pressure Magnehelic Gauge for Racks: C79355

• Ultra-high density
• Fits through standard 36-inch (91 cm) door with cages removed
• Small footprint
• Complete bio-containment and isolation
• Also suitable for invertebrates
• Available single-use caging, interchangeable with standard cages
• Accessory components are available to support a variety of specialized models

Same operating principles as all Animal Care Systems racks?

• One-­pass, low-­velocity airflow with total volume air changes
• No electric motors, no energy consumption
• No noise or vibration
• Prevents release of odours and allergens in the animal room
• Superior cage visibility
• Fast and easy cage filter replacement
• Lightweight and low cost to maintain

Rack Dimensions with Cages and Card Holders
40.5” (103 cm) L x 40.5” (103 cm) W x 76.9” (195.3 cm) H

Rack Only Dimensions
39.8” (101 cm) L x 33.8” (85.6 cm) W x 76.5” (194.3 cm) H

Airflow Requirements per Rack
45 CFM (21.2 liters/sec) minimum; 60 CFM (28.3 liters/sec) recommended

Rack Weight
613 lbs (278 kg) with cages

Rack Casters
Four 4-inch swivel casters; two locking, two non-locking

Rack Capacity
100 cage stations (cages not included)
