Tubing is a relatively small-diameter pipe that is run into a well to serve as a conduit for the passage of oil and gas to the field surface facilities for processing. Tubing must be adequately strong to resist loads and deformations associated with production and workovers. Further tubing must be sized to support the expected rates of production of oil and gas

Most popular related searches

Tubing comes with non-upset (NUE) and external upset (EUE) ends. EUE tubing is more common, because of the benefit that cutting threads into the tubing ends does not reduce the body strength.
Nominal size: is the outside diameter of the pipe body. The most used sizes are: 2-vs" ,i-~a° ,3-^" and 4-s".
The tubing joint length: is the length of tubing joint including the coupling and excluding the pin thread. It is classified into two length range: range I: from 20 ft to 24 ft (6.1 to 7.32 m) long, or range II: from 28 ft to 32 ft (8.53 to 9.75 m) long. The length range must be chosen with care. It must be compatible with the hoisting and storage capacity of the mast of the rig used when running in hole the equipment during completion as well as later on during workover operations.
Package: Steel bundle .Protector on both end .hexagonal bundles of max. 2000kgs with several steel strips, two tags on each bundle , wrapped in waterproof paper. PVC sleeve and sackcloth with several steel strips .
Heat treatment: Normalized , Quencher+Temper

Product Tubing Pipe. Oil Tubing. API Tubing Wei Tubing. Tubing
Application: lised for extracing Oil or Gas from Welts
Size OD: <8.26mnv114.3mm
WT:3.18-18mm
LENGTH: R1.R2.R3
Pipe Standard: API5CTJ55.N80-1.N80-Q.L8O-1. L80-9Cr.L80-13Cf.C90. C95. P110. Q125
Thread: NUE. EUE. VAM TOP equivalent. NEW VAM equivalentHYDRILL CS equivalent, etc.
