Gale Pacific - Model Commercial NinetyFive 340 -Architectural Shade Fabrics
Engineered in Australia, Commercial 95 340 is made from high-quality UV-stabilised HDPE. Strong and stable, it’s suitable for harsh Australian conditions. It`s 100% lead and phthalate-free, and we’re proud to state it is the first architectural shade cloth in the world to be granted Oeko-Tex® 100 and Greenguard® certification.
Most popular related searches
- Knitted lock-stitch construction for fray and tear resistance, offers more air movement and better channeling of cool breezes
- UV-stabilised HDPE monofilament and tape yarn provides optimal balance between strength and UV block, with easy fabrication and minimal maintenance
- Strong HDPE won’t rot or absorb moisture
- Stentered (heat set) virtually eliminates any possibility of shrinking once installed and provides ease of fabrication
- UV Block range 91.1%–95.5% reduces sun exposure for safe and extended time outdoors
- 10-year UV degradation warranty on fabric
- 100% lead and phthalate free for a healthier environment
- Greenguard® and Oeko-Tex® certified provides confidence in operational quality assurance
- Engineered in Australia for the harshest conditions
- 100% recyclable
- Yarn : Knitted UV-stabilised HDPE
- Construction : Monofilament & tape
- Pattern : Lock-stitch knitted
- Temperature range (°C)-30 to +70
- Roll length (m) : 40
- Roll width (m) : 3.00 (folded)
- Nominal fabric mass (gsm) (AS 2001.2.13) : 340 +/- 30
- Approximate thickness (mm) : ~1.6
- Tensile strength – warp (N/50mm) (AS 2001.2.3.1) : 670 N/50mm
- Elongation at break – warp (%) (AS2001.2.3.2) : 117%
- Tensile strength – weft (N/50mm) (AS 2001.2.3.1) : 2400 N/50mm
- Elongation at break – weft (%) (AS2001.2.3.2) : 83%
- Wing tear – warp (mean) (AS2001.2.10) : 184 N
- Wing tear – weft (mean) (AS2001.2.10) : 347 N
- Burst pressure (kPa) (AS4878.5 – Method B)3500 kPa
- Burst force (N) (AS2001.2.19) : 1937 N
- Flammability Index (range0-100) : 12
- Lead : Not detected
- Pthalate : Not detected
