Storike - Model ST8000 -Articulated Double Drum 8 Ton Vibratory Road Roller
Model Number:ST8000. Type:Vibratory Roller. Power:74 KW. Brand Name:Storike. Certification:ISO/CE. Warranty:1 Year. Drum:Double Drum Roller. Vibration frequency:45HZ. Weight:8000KG. Engine Cummins 4BTA3.9-C100. Travel Speed:0-9.2KM/h. Place of Origin:Shandong,China. Dimension(L*W*H):4795*1765*2645mm. Drum diameter:1200mm. Exciting Force:95KN. Fuel type:Diesel. Wheel Size:1200(D)*1600(W)mm.
- Equipped with famous brand engine, could guarantee quality stability and excellent performance.
- Hawkeye-shaped body design, wide field of vision, and beautiful appearance
- Used international famous brand hydraulic pump and motor, which can be steplessly shifted and walk forward and backward.
- LED display instrument panel.
- Assembled with working light and warning light, could work at night.
- Ergonomic chair.
- Passed CE, SGS and ISO certification and won Red Star Award design.
- The steel wheels are equipped with outline marker lamps, could ensure the safety of the operator.
ITEM NO/DETAILS: ST8000
ENGINE:
Engine: Cummins 4BTA3.9-C100
Engine type: 4 cylinders, water-cooled, four-stroke, diesel
Number of cylinders: 4
Output power (KW): 74
Rating speed(RPM): 2400
DRIVING:
Drive mode: Hydraulic drive, hydraulic vibration
Walking speed (KM/H): 0--9.2
Theoretical climbing ability(%): 30
VIBRATION:
Vibration pump: Parker
Vibration motor: Parker
EXCITING SYSTEM:
Vibration wheel: Front
Drive form: Hydraulic Motors
Vibration frequency (HZ): 45
Vibration amplitude (MM): 0.72
Exciting force(KN): 95
SIZE:
Working width(MM): 1765
Overall length(MM): 4795
Machine height(MM): 2645
Turning radius(outer)(MM): 5510
Wheel track(MM): 2540
Drum size(MM): 1200*1600
Tire Model: 14.9-24
(BOMAG)
WEIGHT:
Working weight(KG): 8000
Static load(N/CM): 225
