TOFWERK - Model API-TOF -Atmospheric Pressure Interface (API) Mass Spectrometer
FromTofwerk AG
The API-TOF is a flexible research platform for labs using unique ion source hardware; An atmospheric pressure interface (API) mass spectrometer designed for easy coupling to ion sources with operating pressures between 1 and 1000 mbar. Ready to use in the lab or field.
Most popular related searches
mass spectrometry
research instrument
spectrometer design
PTR-TOF
mobile laboratory
spectrometer
corona discharge
mass spectrometry coupling
pressure reducer
radionuclide
- Convenient, adaptable source-mounting flange – makes installation and interchange of sources fast and easy
- Employs any of our TOF analyzers
- Available as a research instrument or as an OEM component
- 4 differential pumping stages between ion source and TOF with RF and DC focusing optics
- Compact, robust assembly for bench-top or field applications, as shown in photo
- Successfully adapted for many mobile laboratories, including: aircraft, research ships, trucks, and even a zeppelin
- Ideal instrument for research groups developing novel ionization schemes
Example Ion Sources for API-TOF
- Proton Transfer Reaction (Vocus PTR-TOF)
- Extractive Electrospray Ionization (EESI)
- Reduced Pressure or Atmospheric Pressure Chemical Ionization
- Electrospray Ionization (ESI)
- Direct Analysis in Real Time (DART, Ionsense)
- Dielectric Barrier Discharge (DBD)
- Corona Discharge
- X-Ray Ionization
- Radionuclides
