Stratum Reservoir - Model APP-300-S -Automated Probe Permeameter

Scanner that measure gas permeability on both slabbed core and whole core.

Most popular related searches

Probe permeability is a fast non-distructive core analysis method to measure steady state gas permeability on both slabbed core and whole core.
Probe permeability provide highly resolved permeability measurements in formations where routine plus analysis cannot capture the degree of core heterogeneity.
Automated operation and user friendly interface.
Several models are available, both linear direction and X-Y direction.
Permeability measurement possible down to 1mm steps.
Operator can select to measure only parts of the core and skip areas where core is missing, plug hole present etc.
Data can be imported into Corimag Vision software as a log next to the core images for the actual core

Advantages
