Geysir DrillmecModel HH-200.S​ -Automatic and Hydraulic Rotary Drilling Rig

SHARE

Principal Particulars: Drilling depth theoretical: 4.000 m / 13.000 ft with 3 1/2″ DP range 3. Year of construction: 2006. Trailer mounted, fast moving, automatic, hydraulic rotary drilling rig, Drillmec, Mod: HH-200.S.

Most popular related searches

Mast

  • Type: Drillmec telescopic
  • Height: Working stroke 16 m
  • Hookload: 200 metric ton / 441.000 lbs

Substructure

  • Clear working height: 6,7 m
  • Rotary table: 27 1/2″, (not for drilling)

Top Drive

  • Type: Drillmec
  • Capacity: 200 metric ton / 441.000 lbs
  • Torque: 3671 daNm / 26.000 lb.ft
