Filtersafe - Model LEVIATHAN Series -Automatic Brush Filter for Industrial Applications
FromFiltersafe Ltd.
The Filtersafe Leviathan Automatic Brush filters are reliable filters that work hard for you, designed for near zero maintenance. The filters are available with either wedge-wire or perforated screens. Both options use a heavy-duty, highly-durable brush for cleaning high loads of suspended solids with continuous operation.Most popular related searches
- Multi-Purpose Brush Filtration Solution. Optimized for industrial, municipal, and agricultural applications.
- Huge filtration area in small footprint
- Low operating pressure.
- Continual operation – No downtime when flushing.
- Robust design with a single moving part means minimal maintenance.
- Highly effective cleaning with over 99.2% Recovery Rate and full-screen recovery.
- P.V. Design according to: AD2000 Merkblatt.
- Rubber lining on request
- Up to 8,000 m3/h Maximum Flow Rate
- Screens ranging from 200 – 6,000 micron Filtration Degree
- Less than 0.8% Backwash Water Consumption
- 1 bar (14.7 psi) Minimum Operating Pressure
- Up to 80,000 cm2 screen area in a single filter
- AD 2000 Pressure Vessel Design code
- Max. Working Temp 60°C
- Skid Mounting – for plug & play and mobility.
- Rubber Line – for seawater and chemical applications
- Horizontal Orientation – for customized installations
- ATEX & IECEx hazardous area compliance upon request
