DSCYE - Model PAM PAC -Automatic Powder Liquid Polymer Chemical Dosing System
Gear transmission is an important part of mechanical equipment and has the functions of transmitting power and changing speed. Types of gears: According to the mutual development directions of gear transmission design axes, they can be divided into the following three categories: parallel axis transmission, intersecting axis transmission and interlaced axis transmission. Gears driven by parallel shafts include spur gears, helical gears and herringbone gears.
Polymer dosing device
Polymer dosing device is composed of hopper, push screw, electric heater and etc. The effective volume of the hopper can meet the dosage for a long time which is equipped with sight glasses for observing material level monitored by the dry powder level meter. The push screw driven by the high-precision reducer can satisfy the dosage. The electric heater can be installed in the discharge pipe of push screw, and it can prevent the powder from caking.
Polymer dissolving device
Polymer dissolving device is composed of pre-soaking device, tank, and 3 sets of mixers. The pre-soaking device is to infiltrate and mix the polymer powder in advance. The 3 tanks are precast mixing tank, homogeneous slaking tank and solution storage tank, in which there is a mixer correspond to guarantee the homogeneity.
Water supply device
Water supply device is composed of pipeline, manual ball valve, filter, pressure gauge, solenoid valve, stop valve, and the rotor flow meter, etc.
- Continuously working with 3-tank integration design (mixing tank, aging tank, storage tank), easy to operate and maintain, low total cost of ownership
- can be extended as a more automatic 2 storage tank type in accordance with the actual needs
- With powdered or liquid state (optional) dual feed design to meet different needs. Proportional allocation function makes it possible to prepare liquid concentration by requirements
- With uniform and moderate concentration to reduce the agglomeration causing by the improper manual allocation. Blocking of pipe or pump, unnecessary maintenance costs and powder expenses could be well avoided
- Powder feeding hopper with anti-condensation, heating and insulation function can avoid the agglomeration or deterioration
- Powder feeder with RPM LCD display makes the powder feed rate and concentration more precise controlled
- Powder/liquid mixer won the new patent product design, the fusion effect is 100%
- Unique design of automatic intermittent operation and cross mixing function at stand-by time makes the uniform solution always working in the best condition
- When powder feeding hopper reaches the minimum stock, LED light warning and automatic stop function makes overall maneuverability more perfect
- Aid condensation of city sewage
- Aid condensation of industry sewage
- Disposal and deposit of sludge
