Autrol - Model AI 100 -Smart Field Indicator
Autrol Field Indicator, Model AI-100, is an Indicator for converting and displaying received 4 to 20 mA current input to setting range. The Indicator is available to indicate 5 digit numbers, 6 digit letters and 4 type special symbols on LCD. It has main functions such as Displaying 4 to 20mA current, Easy Configuration, Changing Square Root function and User Define Units.
Most popular related searches
- Type: Smart Field Indicator with Unit Selectable
- Certificate: Ex d KCs, IP67
- Advantage: Remote Monitoring with 4~20mA input. Changeable & configurable the device with External buttons.
- Application: Remote monitoring for Level device
- Intuitive & Logical Interface
- 4 ~ 20mA Loop Power
- LCD Display
- Low Voltage Drop
- User Interface (2 Button)
- Flexible Wide Range. (-99999 to 99999)
- Easy Calibration
- User Define Units, Modified Various Units
- Model Name: AI-100
- Protocol: Digital Communication, HART
- Indication Range: -99999 to 99999, 5 digit + 1 sign
- Power supply & Load Requirement: 24 Vdc, Loop Powered
- External Buttons: Zero & Span 2 buttons for device configuration
- Process Temp. limit: -20 to +70°C ( -4 to +158 °F )
- Resolution: ± 0.02%
- Accuracy: ± 0.02% of Calibration SPAN (16mA)
