Bamomas - Bundle Package - Bamomas Battery Sensor +B01 and Analytics (without Gateway Device)
FromBamomas
1. Battery sensor +B01 technical info: Designed for Bamomas cloud-based Battery Analytics service, BLE style radio wireless connection to the gateway, optional set up for Wirepas mesh network, IP68 style completely sealed housing for harsh environments, all measurement leads with M10 bolt size and fuss for safety, NFC for easy set up. Measurement of Voltage with two ports, range 80 - 110 Volts, midpoint 0,5 - 69 V. Current measurement with dual sensitivity range probe. +B01-118 Range, option 1: ± 30 A and ± 350 A. +B01-124 Range, option 2: ± 75 A and ± 500. Temperature Probe for battery housing surface. BFS cap compatible. Battery liquid level detection. 2. State of the art battery analytics includes: Battery Analytics results calculated from the sensor data. e.g. SoC, SoH, Cycles, nominal cycles, temperature and many more. Battery specification stored for analytics reference. All data is stored in cloud computing environment and can be retrieved any time. Instances, maintenance log, and data for warranty. Zoom into the historical data. APIs for integration. Maximise the performance and life of your batteries. Reduce operational costs and improve sustainability with our cloud-based battery monitoring and analytics system powered by custom-designed sensors, cutting-edge IoT and machine learning-based analytics.Most popular related searches
temperature probe
sensor data
analysis system
cloud-based monitoring system
cloud-based analysis system
analytical monitoring system
cloud monitor
cloud monitoring
integrity monitoring
- Bamomas Battery Sensor +B01 with current detection
- Battery analytics app subscription for an unlimited time period
- BLE connectivity to the gateway
- Designed for Bamomas cloud-based Battery Analytics service
- BLE style radio wireless connection to the gateway
- Optional set up for Wirepas mesh network
- IP68 style completely sealed housing for harsh environments
- All measurement leads with M10 bolt size and fuss for safety
- NFC for easy set up
Measurement of
1. Voltage with two ports, range 80 - 110 Volts, midpoint 0,5 - 69 V
2. Current measurement with dual sensitivity range probe
-
+B01-118 Range, option 1: ± 30 A and ± 350 A
-
+B01-124 Range, option 2: ± 75 A and ± 500
3. Temperature Probe for battery housing surface.
4. BFS cap compatible
5. Battery liquid level detection
- Battery Analytics results calculated from the sensor data. e.g. SoC, SoH, Cycles, nominal cycles, temperature and many more.
- Battery specification stored for analytics reference.
- All data is stored in cloud computing environment and can be retrieved any time.
- Instances, maintenance log, and data for warranty.
- Zoom into the historical data.
- APIs for integration
