Feeco - Belt Conveyors

The right bulk material handling system can add automation and fluidity to any application. We offer a diverse range of optional equipment to complement our conveying systems in order to provide you with a complete system designed to handle your specific material. Belt trippers, weighing units, delumpers, reclaiming equipment, loading shelters and load out systems for trucks, rail cars, and barges are all available.

All FEECO belt conveyors and conveyor systems are engineered around your unique application to ensure the best bulk handling solution possible.

INCLINED CONVEYORS

These belt conveyors can be run at various inclined angles, typically between 0°- 20° (30° with cleated/chevron belting). For conveyors that operate beyond this incline, steep incline conveyors, which can operate at angles all the way up to 90°, are also available.

The diagram below shows the relationship between conveyor center-to-center (C/C) length, angle of incline, horizontal distance, and conveyor lift.

TROUGHED SIDE WALLS

Troughed belt conveyors provide high-capacity bulk material handling. The trough design also contains and arranges material in one continuous stream, while at the same time, eliminating spillage. The troughed belt can also help shield material from unforeseen forces, such as airflow from other equipment operating nearby.

DUST CONTROL AT LOAD POINTS

Integrated skirtboard and exhaust ports provide additional control for each customer’s specific application. These are usually located at the tail section of the conveyor where the material is loaded onto the belt. This design centers the material on the belt while also containing dust and fines. A dust pick-off point is often located at the top of the discharge hood.

TRUSS FRAME

Heavy-duty box truss frames are available in several standard depths. This type of frame construction is used when long spans are required between support points. In addition to span length, proper truss selection also accounts for load factors such as wind and snow.

CHANNEL FRAME

Conveyors that do not require long spans between supports may benefit from the channel frame design. Because they are often located close to grade, a cantilevered walkway is not required. Above all, channel frame conveyors receive the same precision engineering expected from all FEECO material handling equipment.

All FEECO belt conveyors feature:

Additional Options

• Size: 18” – 72” wide
• Capacity: up to 8,000 TPH
• Standard troughed belt conveyors are comprised of conveyor belting that rides on heavy-duty troughed idlers. Idlers range in angles from 20°-45° and are securely mounted to a structural steel frame.
