Berkelmans Welding - Model 10 Ton -Wheeled Excavator Trailer
At Berkelmans Welding & Manufacturing, we take pride in crafting top-of-the-line equipment for the construction industry. Introducing our flagship product: the 10 Ton Wheeled Excavator Trailer, a custom-made off-road solution designed to seamlessly hook up to your excavator, empowering your construction projects with unmatched efficiency and durability. Why Choose the 10 Ton Wheeled Excavator Trailer? Custom Craftsmanship: Our trailers are meticulously crafted to meet the unique demands of the construction industry. Each unit is a testament to our commitment to quality, precision, and innovation. Robust Design: Built to withstand the toughest terrains, our 10 Ton Wheeled Excavator Trailer is engineered for durability.
Most popular related searches
- Molded steel floor bent as one pan.
- AR 400 hardened and wear resistant 3/16” floor and sides.
- Front puncture proof 5/16 plate rolled to allow bucket to scoop max loads out of trailer.
- 3” x 6” x .188 tube main frame.
- Unibody body long sill, 100% welded to floor.
- All joints, seams and posts are welded 100%.
- 84” box inside width.
- 120” inside length.
- 92” outside width.
- 15ft2” total length.
- Side from ground without board extensions.
- 69” high with the board extension.
- Dump headroom required 132”.
- Walking beam suspension.
- 8000 lb per spindle load rating.
- 500/60/17 x 18 ply tires, optional
- 400/60/15.5 x 14 ply.
- Hydraulic surge brakes optional.
- 15-ton hydraulic cylinder 2.3 gallon oil capacity.
- 54-degree dump angle.
- Hydraulic tailgate. Barn door tailgate optional.
- Taillights
- 4000 lb empty weight.
- Automotive grade metal treatment and primer, topcoat with high quality alkyd.
- (test results show that this metal treatment and primer superior to powder coat in scratch and rust resistance)
- Trailer Weight: 4000 lbs
- Capacity: 20000 lbs
- Dump Angle: 54 degree
- Dimensions:
- 84 inches box inside width x 120 inches inside length
- 15 ft 2inches total length
- 69” high with the board extension
- Width Outside Box: 92 inches
- Tires:
- 500/60/17 x 18 ply tires, optional
- 400/60/15.5 x 14 ply
- Colour: Your Choice
- Headroom Required: 132 inches
- Drop Leg Jack: 8000 lb
- Spindle and hub load rating: 50000 lb
- Optional
- Hydraulic surge brakes
- Hydraulic tailgate
- Barn door tailgate
