Binhe - Wedge Wire Screen Machine
Two-axle CNC control, servo motor drive, high welding precision. Two working methods: manual and auto. Under Auto method, by inputting relative data, the machine will work automatically. Strong self-diagnose function, can display any mis-operation alarms, Alarming error can be seen from displayer.
Most popular related searches
Figuration of wedge wire screen machine:
- CNC control system: Siemens 6ES from Germany
- Servo motor and servo driver: Mitsubishi from Japan
- Ball screw: ABBA from Taiwan
- Linear rail: famous brand from Korea
- Filter tube diameter range: 60-600mm (can be max. 1200mm)
- Filter tube length: max. 6m
- Suitable wire: stainless steel or carbon steel, diameter 1.5-5mm
- Space between welding lines: 0.1 to 16mm
- Welding precision: if wire diameter tolerance is within 0.01mm, welding precision will be within +/-0.03mm
- Welding speed: 6-30rpm adjustable based on tube diameter
- Welding transformer power: AC 200kW
- Driving motor power: servo motor 2kW x 3
- Tool changing speed: within half hour
- Dimension: about 11m x 1.4m x 2.5m
- Weight: about 5 tons
