BinMaster - Model BM-45-RH-730-0005 -Diaphragm Switch
Diaphragm switch with heavy duty .031” thick, black neoprene diaphragm, internally mounted. The BM45 standard pressure switch alerts to high or low levels in bins containing non-hazardous, free-flowing dry materials.
Tired of climbing bins to know if they are full? Want to stop overfilling bins?
Get affordable point level control for bins containing free-flowing dry solids with a density >20 lb./cu. ft.
How it works:
When material presses against the diaphragm, it activates a sensitive micro-switch that can be wired to start or stop a process or alert to high or low levels in bins using a horn or alarm.
Diaphragm switch features:
- For bins and some plugged chute applications
- Rugged construction and simple design
- Die-cast aluminum housing
- Neoprene or silicone diaphragm material
- Internal or external mount
- Multiple voltages
Overflow Prevention
High-level alerts to avoid overfilling vessels
Material Outages
Low-level alerts eliminate empty conditions
Plugged Chutes
Detect when chutes are clogged with material
Process Control
Switching relay to turn a process off or on
Conveyor Overload
Prevent jamming or damaging conveyors
- SKU: 730-0005
- Means of Measurement: Pressure Switch
- Measurement Type: Point Level
- Medium: Solids
- Voltage : Up to 480 VAC
- Outputs: Relay SPDT
- Ambient Temperature: -40°F to +300°F (-40°C to +148°C)
- Process Temperature: Up to +300°F (148°C)
- Enclosure Material: Die cast aluminum
