Kotech - Model KR-2 -Binocular Research Microscope
Kotech Export presents a unique range of Coaxial Microscopes for use in different type of laboratories. We are the market leaders in providing Pathological Binocular Microscope with Co-axial focussing control, which find applications in advanced research work in medical laboratory education. These microscopes are easy to use and helps the students to understand the practicals which they read in theoretical subjects. These find usage in medical labs and colleges around the world. In medical and surgery sciences, these microscopes feed enquiring minds of beginners, explorers and experts alike.
Our coaxial binocular microscope consists of a quadruple ball bearing nose piece along with rotatable binocular head with hard coated prisms. A CO-AXIAL mechanical stage with buit in light arrangement hepls in reducing the amount of fumbling around for the controls, and allow you to keep your eyes looking down the eyepieces instead of looking for the stage controls. A separate coarse and fine motion knobs with locking device is offered to avoid damage to valuable slides. This Microscope is packed in moulded styrofoam box, with operation manual, dust cover and cleaning cloth. Wooden cabinet with lock and key are also available according to the customers need.
- Eye Pieces: Two 10x wide field Eye-piece
- Objectives: 4nos. objectives, Parfocal Achromatic, 4x, 10x, 40x SL and 100x SL oil immersion
- Stage: Horizontal Mechanical of size 120x125mm min
- Focus: Coaxial focussing control
- Illumination: 6V, 20W Halogen lamp with on/off switch, light intensity regulator and Plano concave mirror attachment suitable for 220V, 50Hz. AC supply
- Field of Study: Pathology Department
