Blueprint - Model SeaTrac Standard -Acoustic Positioning Systems
The SeaTrac Standard system contains both an X150 USBL beacon and an X110 transponder beacon, everything required to track the position of ROVs and AUVs in real-time down to a depth of 2000m.
Most popular related searches
- Simple, robust position tracking system for deeper water applications
- AHRS and Active Doppler Compensation equipped beacons for reliable and accurate location data
- Stainless steel housings promote longevity on larger inspection class ROV installations
- Intuitive SeaTrac PinPoint software interrogates up to 14 beacons for real-time relative and actual positional data
- Accepts an external heading input and outputs a NMEA string for use in other devices
- X110 beacon can be powered from a battery for standalone diver tracking
- OEM systems and software SDKs available for integrators and developers
