Boschung - Model SOBO3+ -Conductivity Measurement System
The SOBO³âº applies the method of conductivity measurement to determine the leftover quantity of salt/calcium chloride on a surface. Connected to the SOBO³âº mobile application, the SOBO³âº displays on the screen and on the mobile application the measured information, such as the amount of residual salt/calcium chloride, pavement temperature and instantly reports to the maintenance center. Being aware of your surface condition in real time with geolocalization will give you the keys for smart decision making.
Connected for smart and real time decision making
Connected to the SOBO application on your smartphone, the SOBO³⁺ delivers the information to the maintenance center in real-time with the exact geolocalization.
Measurements
-
Measurements can be taken in
- g/m²
- lbs/ lane mile
-
Measuring liquid
2 possible solutions with technical acetone and distilled water
- 100% distilled water
- 85% distilled water with 15% technical acetone
-
Tank capacity
1.5 l (approx. 35 measurements)
-
Volume of fluid injected per measurement
41.5 ml ± 1 ml
-
Displayed measurement
range 0 to 50 g/m2
resolution 1 g/m2 -
Measurable de-icing agents
- NaCl
- CaCl2
-
Pavement temperature
range -30 °C to 75 °C
resolution 0.1 °C
