- Control system: The man-machine interface, color LCD touchscreen
- Temperature range/Temperature fluctuation: RT+10 °C~70°C/less then ±3°C
- Humidity range: ≥95% R·H
- Center distance of the lamp: 70mm
- Distance between sample and tube center: 50±2 mm
- Wavelength: UV-B Wave (280~315nm) or
- UV-A Wave (315~400nm)
- Specimen size: 50×125 mm
- Water and consumption: Distilled water, 8 liters/day
- L=1220, 40w, 8 UVB or 8UVA
- Studio size: W1300xD500xH1460mm
- Uniformity of temperature and humidity: ±3ºC and ±2%
- Fluctuation of temperature and humidity: ±1ºC and ±2%
- Irradiance: 1000uw/cm2
- Power: AC 220V 50HZ 5KW
- Weight: 150KG
- Electronic-eye irradiance control system.
- Use a blackboard temperature sensor providing precise temperature and recurring test results.
- Perform humidifying, condensation, and water spraying circulating tests.
- Irradiance is calibrated by a CR-10 calibrator and automatic calibration procedure (Paten technology).
- Specimen size and quantity: 75mm×300mm 24pcs, 75mm×150mm 48pcs.
