Brentwood -Â Model CF1200 -Cross-Fluted Fills
CF1200 has been designed for use in factory-assembled counterflow towers in HVAC and light industrial applications. It can also be used as a distribution pad in 3.9” (100 mm) and 5.9” (150 mm) depths where the water contains very low levels of total suspended solids. CF1200 splits the water stream ten times in an 11.8-inch (300 mm) vertical path, balancing high thermal performance and low pressure drop.
- Available in material meeting Cooling Technology Institute (CTI) Standard 136
- Available with AccuShield technology
- Available with Mechanical Assembly technology
Highly Efficient
Cross-fluted fills offer the highest level of efficiency of all film fill designs, improving heat transfer and maximizing overall tower performance.
The engineered microstructure incorporated into cross-fluted fills enhances water distribution and thermal mixing.
Brentwood`s cross-fluted fills feature bonded edges for added media strength and durability.
Beveled tips are incorporated into the cross-fluted design to promote drainage at the fill pack interfaces.
Brentwood`s patented Mechanical Assembly technology permanently assembles fill packs without glue by crimping the male and female attachment tabs molded into the individual sheets.
