Particles Plus - Model UM-27000 -Brush and Brushless Rotary Vane Vacuum Pumps
The Particles Plus Brush and Brushless Rotary Vane Vacuum Pumps produce either vacuum or pressure by compressing or expanding a volume of gas within a cylindrical steel housing. Within the housing is a compressed graphite rotor with two slots that contain compressed graphite vanes. The rotor is mounted to the shaft of the motor and is positioned off-axis to the center of the steel housing. As the motor shaft rotates, the vanes are pulled outward by centrifugal force.
The vanes then make contact and slide against the inner surface of the steel housing, forming two internal and enclosed volumetric areas, which increase or decrease as the rotor turns, with a vacuum being created on the increasing side and pressure on the decreasing side.
There are two ports positioned at the points of minimum volume with the increasing side being the vacuum port and decreasing side the pressure port.
- 0.19 CFM (5.5 LPM) open flow rate
- Suitable for pressure and/or vacuum
- Oil-less
- Compact design
- Low vibration
- No valves
- Nearly pulsation free
- Self-lubricating and self-adjusting vanes
- Good controllability
- Automotive
- Analysis
- Automation
- Environmental
- Food and Beverage
- Instrumentation
- Laboratory
- Medical
- Dimensions (L x W): 2.25” x 1.2” (5.6 cm x 3.0 cm)
- Weight: 0.22lb (0.1 kg)
- Power: 6 VDC
- Operating Conditions: 41º to 104ºF (5º to 40ºC) / 20% to 95% non-condensing
- Storage Conditions: 32º to 122ºF (0º to 50ºC) / Up to 98% non-condensing
