Height-LED - Model HTCD-II-FS200200-BH -Cabinet Type Uvled Curing Machine(200x200mm)
Height-LED specializes in the manufacturing of advanced UV LED curing machines designed for a range of industrial applications. These machines utilize ultraviolet light-emitting diodes to facilitate processes such as printing, coating, and bonding by curing or drying inks, coatings, and adhesives. The curing machines are part of a broader suite of products which include UV lamps, UV machines, and specific systems for applications in furniture, flooring, optical communication, precision optics, among others. Additionally, they provide solutions for electronic components like PCBs using UV LED technology. Height-LED's equipment emphasizes efficiency and precision, incorporating modular designs for varied user applications. Their technology offers streamlined integration into existing production lines, improving drying times and curing processes over traditional methods. The company is committed to innovation in UV curing technology to meet the specific needs of industries that demand high-quality and reliable curing solutions.
Cabinet UVLED curing machine, instead of traditional mercury lamp, built-in UVLED curing light source, low temperature, no ozone, no deep UV, low energy consumption, high efficiency.
1, the device supports real-time monitoring of UVLED current, UVLED failure alarm function and energy-saving protection function.
2, the device provides continuous mode and back-end mode optional, continuous mode, click the start button, the UV machine conveyor belt and UVLED has been working, click the stop button to stop the UV machine work; back-end mode, click the start button, the UV machine conveyor belt and the UVLED began to work, when the back-end sensor sensor to the product, the conveyor belt and the UVLED stop working, when the product is taken away to continue to the next cycle. The product is taken away and continue to enter the next cycle.
3, the equipment has a digital dimming, delayed shutdown fan heat fan, history of irradiation time query and other functions.
- Main Model : HTCD-II
- UV machine external dimensions : l1200mm*w470mm*h980mm
- Light source size : l253mm*w240mm*h110mm
- Lighting area : 200mmX200mm
- Wavelength : 365/385/395/405 (optional)
- Optical power density : 365nm 385nm 0.8W/cm² (10mm irradiation distance)
- Lamp bead brand : 395nm 405nm 1.2W/cm² (10mm irradiation distance)
- Lamp Bead Life : Seoul, Korea
- Heat Dissipation : ≥20000H
- Control mode : Air-cooled
- Parameter setting : PLC control
- Power Adjustment : Touch screen operation
- Speed Setting : Digital dimming (10-100%)
- Power supply voltage : 0.5-5m/min
- Power consumption : AC100V-AC240V (50/60HZ)
- Net weight : 1000W
- Ambient temperature and humidity : 65KG
- Warranty time : Ambient temperature: -20℃-40℃ Relative humidity: 25%-80%RH
