SEDA - Cable Cutter

The module one is modular in design and can be expanded to include a gearbox drill, shock absorber drill or even a quality control unit. Its single stem design uses very little space and can be used with any hoist or ramp, even between two hoists. The compact design makes the module one ideal for smaller dismantlers or where space is at a premium.

2 versions are available.

S-528173 Module ONE

• Space saving single column with platform for 3 Pumps
• 3,1 inch air pumps and accessories for petrol/diesel, oil and coolant removal
• Award winning SEDA Heavy Duty SEDA-Fuel Tank drilling machine
• No mess raisable swing arm and extra large funnel for engine and gear oil removal
• Petrol, diesel and oil filters
• Air processing unit, for dry oiled air, Improves reliability
• Break fluid Kulie and accessories for break fluid removal.

S-528172 Module ONE Plus

• A sturdy base for a pump
• Extra pump and hose real for coolant removal
• Brackets to fit the fuel pump to the tank drill

More benefits of the SEDA-Module ONE:

• Saves time and space
• Easy handling
• Suitable for use with different types of lifting platforms
• High quality components and pumps
• EX and ATEX certified. Virtually eliminates fire and explosion risk

Performance:

• drainage time of under 7 minutes

Air pressure required:

• approximatly 1000 L @ 8,5 bar

Total air required:

• 3 m³ / per vehicle

Performance/Pumps:

• Petrol/Diesel 15 Liter/min.
• Waste oil/Coolant fluid 5 Liter/min.
• Screenwasher fluid 8 Liter/min.

Space required:

• 6,0 meter length
• 4,5 meter width
• 3,8 meter heigth

Swing arm radius:

• 6,0 meter fully extended
