Schnell-Teknik - Calculate Optimum Belt

If the fluid level changes a lot you should always use the lowest level as an indication, eg.:

If you get the result 860 mm using the above formula, you should choose the nearest lower standard belt length - in this case 800 mm. This belt will be the correct for the job.

If you are in any doubt please contact the factory or your distributor. We manufacture belts on special request too.

• Height of vat = H
• Formula: Type A, B, C, 28, 33, 35 , 38, 39:  (H+70)x2=Belt length mm.
• Formula: Type 41, 42, 58, 59:  (H+120)x2= Belt length mm.
• Formula: Type 56:  (H + 175) x 2 = Belt length
