Design Filtration Microzone Inc. (DFMZ )

DFMZModel NXT HEPA -Carbon Extraction Hood

SHARE

 The Design-Aire SL-REV is our standard SL model with reversed air flow direction. These units are typically used to create negative pressure enclosures, where the exhausted air is required to be filtered.  They are also used as air returns in clean rooms that are ducted back into the buildings` HVAC systems.

Most popular related searches
  • Operator Protection: The airflow is directed away from the operator, into the hood to be filtered. Both the NXT-310 and 410 models have been successfully ASHRAE 110 tested with excellent results.
  • Particulate Filtration: Contaminated air passes through a HEPA filter rated at 99.99% with the filter located at the exit point of the cabinet, allowing a full leak scan.
  • Chemical Filtration: Contaminated air passes through a carbon filter designed specifically to the chemical to be absorbed in each hood.
  • Independent Operation: Internal fan(s) direct air without the need for the air to be ducted to the building system. The filtered air is vented back into the room, saving otherwise wasted energy.
  • Sturdy Construction: Constructed from cold-rolled steel with anti-bacterial powered coating, Interior 304 stainless steel with coved corners, two layers of laminated, toughened, anti-UV glass, and an electroplated work surface.
  • 36” standing height base frame
  • ULPA filter rated 99.9995% efficient at 0.12µ
  • 230V, 50HZ power configuration
  • Stainless steel IV bar and hangers
  • Stainless steel side panels
  • Transition adaptor canopy for hard connection and thimble type applications
  • Use for when powders or other potenitally harmful particulates and gas phase contaminants are present in the work zone.
