Veenhuis Machines B.V., Brand of SV Group
Carrier Hook Armsystem
The Carrier, the hook arm system of Veenhuis, enables you to carry out more work while using only one undercarriage. The Carrier has a compactly constructed chassis with an integrated hook-arm system. The low chassis enables high construction with a low centre of gravity and low weight. The entire chassis is used as support for construction, which prevents peak loads in the chassis.
Most popular related searches
water tank cleaning
PTO pump
pressure regulator
water tank
hydraulic cylinder
tank cleaning
plastic cleaning
- Hook height in mm 1.450
- Chassis length of hook -arm in mm 5.600
- Capacity in kg 20.000
- PTO speed 1.000
- Base Tandem
- Tyreheight in mm Max 1.350
- Chassis radiated and sprayed in 2-component lacquer
- Axles fitted with hydraulic suspension
- Hydraulically forced steering
- Hydraulic brakes on all wheels
- Driving height sensor
- Mudguards at front and rear of wheels
- Underside tow bar with fixed towing eye Ø 50 mm
- Hydraulically suspended draw bar combined with short top bar cylinder
- Hook height 1,450 mm
- Hydraulic jack-foot with manual pump
- Container hook-arm system with auxiliary cylinder and hydraulic locking
- Large PTO pump 110 1/min 1,000 revs per minute
- Automatic top bar block during coupling/ uncoupling
- Stamping of hydraulic spring washer when tipping
- Electrically operated CANbus system, including control panel inside tractor
- Lights with double rear lights
- Reverse light
- Scharmüller ball coupling
- Axle lift on first axle
- Airbrakes / Automatic Locking Retractor
- PTG Tyre-pressure regulation system
- Mechanically adjustable hook height
- High-speed function for quickly uncoupling empty containers
- Hydraulic connections for activities such as tailgate or pump drive operation
- Tarpaulin rack
- Plastic storage box
- Clean water tank
- Load-sense, open and closed system
- Additional lights
- PVG certification for Belgium
- Range of tyres
