CDS - Model 8500 -Automated Purge and Trap Concentrator
The 8500C delivers the same combination of quality that made the 7000 series such a reliable instrument, but with plug and play connectivity to the CDS 8500A autosampler. The 8500C features the foam sensor, an inert coated wet trap and a 8 port pneumatics systems, all providing the highest available performance and unrivaled chromotographic resolution.
This industries highest programmable valve oven expands the capability from VOC`s defined in EPA 8260 into the sVOC range
Unlike other brands, CDS adopts 8 port valve to offer a unique capability to isolate the wet trap during desorption step, which improves the efficiency of the water management.
The plug and play setup for the 8500C with 8500A autosampler would quickly add 24/7 sampling capablity to your lab
The newly designed wet trap is coated with Hydroguard for optimized moisture control with maximized life span
The quick access panel offers a convenient way to maintain the sample pathway to minimize any service downtime
This patented sensor eliminates the possibility of sample foaming and subsequent contamination of the sample path way.
The 7000C is capable of handling both 5 ml and 25 ml sample volume, depending on the sensitivity requirement of your analysis
The heated sparge vessel adds two folds of value to the system; purging at an elevated temperature to improve sensitivity, and reducing carryovers to help keep the sample path way clean.
The 8500C Purge and Trap concentrator is seamlessly integrated to the 8500 workstation control software and method editor.
