CEC Tanks - Anti Corrosion Glass Fused ...

CEC Tanks - Anti Corrosion Glass Fused Steel Tanks

Glass fused to steel tank is the prefabricated tanks, which made of Ti-rich steel sheet and enamel frits.The steel plates are coated with enamel powder and burned in oven which makes them superior connection with both . Glass fused steel tank is wide used in water supply and wastewater treatment , biogas or anaerobic digester, and dry bulk storage field .

Most popular related searches

glass fused steel tank

Design Life: 50 Years
Coating Thickness: 0.25mm~0.40mm , Two Layer Of Coating Internal And External
Foundation: Concrete Or Glass Fused Steel
Size Of Panel: 2.4M * 1.2M
Feature: Eco-friendly, Durability
Applications: Water , Waste Water, Digester , Reactor , Grain , Sludge , Chemicals

Quick Details of GFS tank

Type : Glass fused anaerobic digerster tank
Color : Cobalt blue,green , sky blue,or custom color
Usage : Wastewater , faeces ect.
Roof : Double membrane roof,glass fused to steel roof
Size : From 50m3-18000m3
Service Life : more than 30 years
PH range : Standard sheet PH:3-11 , Special sheet PH : 1-14
Holiday test : More than 1500V
Corrosion resistance : Excellent ,suitable for wastewater , salt water , sea water , high sulfur crude oil , salt fog , organic and inorganic compounds
Hardness : 6.0 mohs
Elastic : Same as steel sheet , around 500 KN/mm
Adhesion : 3,450 N/cm

Glass coated steel tank is wide used as anaerobic tanks and aerobic tanks in the field of biogas plant.
Glass coated steel tank is used as edible oil tanks, feed tanks,grain tanks, wine tanks, and so on.
Glass coated steel tank is used as waste water containers, filters, digesters, bio-reactors, waste water settling tanks, intermediate process tanks, sedimentation basin, fermentation tanks, etc.
Glass coated steel tank is also used in fire and rescue system and agriculture irrigation storage system .
