Graymills - Model HV Series -Centrifugal Pump
Centrifugal pump for use on small presses requiring flow rates of less than 1 GPM and viscosities up to 30 sec. No.2 Zahn. These pumps have a high strength thermoplastic pump body, stainless steel shaft, ½” NPT discharge tube, and agitor jet for in-tank circulation. Available in 1 or 2 gallon tank size. Non-explosion-proof, and air motor options.
Most popular related searches
centrifugal pumping
centrifugal pump
thermoplastic pump
pump system
ball valve
centrifuge
plastic tank
stainless steel tank
steel tank
container lids
Typical Applications
For small presses requiring flow rates 1 GPM or less. Viscosities up to 30 sec., No. 2 Zahn.
Standard Features
- High strength thermoplastic pump body
- Stainless steel shaft
- Ball valve and 1/2” NPT slip-on barb on discharge tube
- Agitor jet for in-tank circulation. (Agitor port may be plugged if circulation is not desired)
- 1 or 2 gallon container with flanged lid with 3/4” (19mm) hole for return hose
Motor Options
- 1/15 HP, 3000 RPM@60Hz (2500 RPM@50Hz) electric
- Variable speed air motor, 0-3000 RPM
Motor Voltage/Air Options
- A, B, GAM (#1)
Tank Options
- 1 gallon (HV1), 2 gallon (HV2)
- Plastic tank with nickel-plated lid or stainless steel tank with stainless steel lid
