Begg - Ceramics
Begg Cousland can supply high quality, competitively priced ceramic saddle and ring packings for chemical process towers including for Sulphuric Acid and Chlorine production, carefully sourced from our partners.
Most popular related searches
Typical Ceramic Saddle Chemical Composition (%) :
- SiO2 70.21 – 74.51
- Al2O3 19.79 – 23.13
- Fe2O3 0.38 – 1.15
- CaO 0.1 – 0.52
- MgO 0.27 – 0.88
- K2O 1.32 – 3.40
- Na2O – 0.20
- Ti2O 0.01 – 0.15
- Temperature resistance, 1460°C
- Water Absorption: 0.11-0.15%
- Porosity: 0.25-0.35%
- Losses in Sulphuric acid by ASTM C-279: 0.07-0.23%
- Real density: 2300kg/m3
- Heat Conductivity:
- 1.412W/(m.K) at 200°C
- 1.427W/(m.K)at 500°C
- Thermal Expansion, mm/mm.°C 4.7-5.6x10"6 Hardness: HM 7.2
