Ennex - Chain Guided & Drum Guided Conveyor

• residual waste like household- and bulky waste
• mixed waste like industrial waste and recycling wood
• waste from separate collections like light packaging, pasteboard paper, cardboard, bio waste or compost

These heterogeneous types of waste make demand of the high standard conveyor technology, which must provide different basic functions:

• feeding conveyors, under and over floor
• conveyor, upward conveyor, sorting conveyor etc.

Technically, this demands can be realised with different types:

• chain-guided conveyors like roller chain conveyors or plate belt conveyors
• drum-guided conveyors like sliding-bottom conveyor and carrying roller conveyor

Chain-guided conveyors have a very sturdy construction, in which the belt is moved by a fixed connection between support ledges and chain, which runs over chain wheels. In the drum-guided conveyor, the tensed belt runs over a drive- and a redirection drum.

Years of experience led AMB to an own, proved modular system. Target is a low vulnerability to failures and therefore a high availability of the whole plant. At the same time the modular construction with mostly standardised and screwed elements provides a high flexibility for coming upgrades or rebuilding. Main feature here is a closed support frame in different construction heights with openings for service purposes.

Drive- and redirection segments with their tense station are adapted in different lengths, just like the height of the material guiding ledges and the side sealing of the belt.

The target of AMB is to provide the matching conveyor technology for every kind of waste.
