HSM - Model VK 1210 -Channel Baling Presses / Channel Balers
FromHSM GmbH Co. KG
For industrial applications with small to medium material loads, e.g. processing industry, PET bottles / UBC disposal, document shredding facilities, printing and paper industry.
Most popular related searches
channel baling press
channel baling
baling press
channel baler
PET bottle
document shredding
baler
baler industry
PET bottle shredding
industrial baler
- Suitable for applications with a throughput up to approx. 110 m³ / hour
- Similar to VK 1206, with larger loading length
- Particularly suitable for cardboard, foils and PET bottles / UBC
- Loading aperture of 1000 mm suitable for larger material pieces and higher throughput rates
- Available as an option with manual strapping
- Suitable for continuous loading
- Variety of uses
- Suitable for many different materials
- Operating side can be selected
- Control of compression cycle via light barrier
- Compact bale dimensions
- Low space requirement
- Approved system solution and technology
- Voltage: 400 V
- Frequency: 50 Hz
- Width: 2350 mm
- Height: 1820 mm
- Weight: 3800 kg
- Loading aperture width: 620 mm
- Pressing power: 160 kN
- Bale length: 600-1200 mm
- Bale width: 700 mm
- Driving power: 9,2 kW
- Bale height: 500 mm
- Cycle time in idle operation: 11,5 s
- Bale weight (max.): 100-200 kg
- Length: 5550 mm
- Specific pressing power: 45,7 N/cm²
- Number of strappings: 3
