CHARMSSTONE - Model PH12 Series -Plastic UV Ballast
CE UL approval. Preheat start. Advanced driver IC. Wide range voltage, constant power. Local/remote working condition indicator.
Most popular related searches
- Rated Supply voltage: 99~264V/50~60Hz
- Voltage Range: 99V~264V
- Operating Frequency: 50/60Hz
- Maximum Input Power: 26W
- Input Frequency: 50Hz
- Efficiency: ≥88%
- Start Type: Preheat start
- Power Factor: ≥0.55
- Ambient Temperature: -5~40℃
- Humidity：5%~85%
- Maximum Case Temperature: 70℃
- Certificate: CE, UL
- Power Range: 4~26W
- Tube Current: 180mA,350mA,425mA
- LED indicative function: green when UV lamp is in normal operation; red when UV lamp is out.
- Selection of cables: 0.5~1.0mm.
- Stripping length: 8-10mm.
- Cablesbetween ballast and lamp:≤ 5m
- Short circuit is not allowable for any two output cables.
- Mustcutoff the power supply before installation and replacement ballast.
