Suncenter - Model DLS -Chemical Injection Pump

• MOQ: 1 Set
• Brand Name: SUNCENTER
• Certificate: ISO/CE/SGS
• Warranty: 13 Months
• Packaging: by Plywood case
• Shipping Port: Shenzhen/Hongkong
• Payment: T/T, Western Union, Credit card.
• Transaction method: EXW, FOB, DDP, CIF, CFR
• Place of Origin: Guangdong Province, China (Mainland)
• Delivery Time: Within 10-15 working days after received deposit.
• Suncenter Oilfield chemical reagent injection system
• Pneumatic chemical reagent injection booster system

Product introduction:

Chemical reagent injection system is widely used in the world oil production and processing industry. Using the  Air / gas driven system to filling chemicals to the oil wells, gas wells and pipelines, restore the normal work of the oil (gas) well, also can be used for delivery of raw materials to the high-pressure reaction kettle quantitative.

The effect of the chemical injection system is to use a chemical injection system to return or inject a liquid chemical agent into the fluid at high pressure or low pressure. To return fluid injection of chemical agents usually using methanol, preservatives, deoxidizer, drilling fluid additive (caustic soda and liquid polymer) and defoaming agent. Chemical injection system is a relatively simple system, its suction end is using pneumatic piston pump, the pump and chemical agents are connected to the container. And the discharge end is directly connected with the pipeline.

1. Oil well
2. Gas well
3. Reaction kettle

1. Equipped with high quality pneumatic chemical reagent injection pump, can easily achieve the output pressure and flow of any adjustable, controllable;
2. The contact liquid section is stainless steel, strong corrosion resistance, suitable for a variety of chemical reagents; (also can use the gas system)
3. It can be used in a variety of pressure level of the wellhead, the system with the function of the pressure starting;
4. Chemical reagent injection system output pressure is high, 6.0-640 MPa is arbitrary, the system has to stop working under the set pressure;
5. Advanced technology, reasonable structure design. The features of small size, light weight, beautiful appearance;
6. By air/gas driven, no need to use electricity, there will be no spark generated, safe explosion-proof;
