Waterman - Model CPF-E -Chlorine Dioxide Generator for Water Treatment System

Basic Info

• Model No.: CPF-E
• Brand: Waterman
• Capacity: 50-20000 G/h
• Feature: Safe, Reliable, Easy To Use, Intergrated
• Application: Drinking Water, Cooling Water, Swimming Water, Waste Water Treatemnt
• Control: PLC Auto Control

Additional Info

• Packaging: Plywood box
• Productivity: 500 sets per month
• Brand: Waterman
• Transportation: Ocean,Land,Air
• Place of Origin: China
• Supply Ability: 500 sets per month
• Certificate: ISO9001,CE
• HS Code: 8419200000
• Port: Shanghai

• Place of Origin: Jiangsu, China (Mainland)
• Model Number: CPF-E
• Output: Clo2: 50~20000g/h
• Conversion Rate: 98%
• Material: PVC (shell), Titanium (reactor), PTFE(tube)
• Control: PLC control
• Raw Material: NaClO2and HCl
• Power: Electric
• Certification: ISO 9001, CE, SGS, IAF

Structure

Main parameters:

• Working temperature: 5 ~ 40 degrees Celsius
• Operating voltage: 220V plus or minus 10% / 380V plus or minus 10%
• Operating current: <10A
• There should be no strong electric field and magnetic field interference around equipment.
• Maximum pressure of water-pipe-line: <0.7Mpa
• Function: PLC control, Computer Remote Control, Work data records
• Flow control, Residual-chlorine-on-line display, or manual control
• Low liquid level alarm of raw materials
• Linkage with water pump
