Keestrack - Model C4 -Classifier C Series

• Compact high production classifier - 3 & 4 split
• Double or Triple deck screen box 3.600 x 1.500 mm (12’ x 5’)
• Fuel saving load sense piston pump technology
• Auto sequential start as standard
• True mobility, no support legs under feed hopper
• All decks are interchangeable
• Capacity up to 400 tonnes / hour
• 5,4 m² screening surface on each deck
• Feed hopper 8 m³ (10 yard³)
• Low emission engine
• Interchangable screen meshes on all decks
• 2 speed track drive

Weight
25 t (27 sT)
28 t (30 sT)

Length
13.700 mm (44’11”)
13.700 mm (44’11”)
15.850 mm (52’)

Height
3.150 mm (10’4”)
3.325 mm (10’11”)
4.240 mm (13’11”)

Width
2.550 mm (8’4”)
2.800 mm (9’2”)
14.400 mm (47’3”)

• Quarrying 0-4, 4-8, 8-16, 16-32 and others as specified
• Sand and gravel
• Separation of aggregate
• Construction and demolition
• Screening behind a crusher
• Coal and others
