ClearSky PLUS - Inrush Mitigation Solution
ClearSky PLUS is an advanced, patented modular interconnection solution designed for whole facility inrush mitigation. It employs a specially engineered pre-insertion transformer that is activated during the initial energization phase of a facility to curb inrush current. Once normal operations commence, the transformer is deactivated to maintain operational efficiency. This system ensures compliance with power quality standards set by utility companies. The product includes integrated capabilities for event capture and reporting, essential for fulfilling utility audit requirements. Additionally, ClearSky PLUS offers features such as pre-assembled, self-contained design, remote monitoring through a browser-based user interface, and reduced installation costs due to ground-level equipment access. Optional features allow customization to meet specific utility needs, further optimizing installation and safety. It transforms potential energy inefficiencies into streamlined operations, aligning with industry standards and technological advancements.
Everything you love about the ClearSky Interconnection,
PLUS …
ClearSky PLUS is a patented* modular interconnection solution which includes a specially designed pre-insertion transformer. It is switched in-circuit during initial facility energization to limit the amount of inrush current, then switched out-of-circuit for normal facility operation. The result is automated whole facility inrush mitigation ensuring power quality standards required by utilities are met.
Turnkey Reporting for Utilities & Third Party Engineers
Pass your utility audits with confidence, removing barriers to commercial operation.
The ClearSky PLUS supports integrated event capture capabilities that demonstrate the successful inrush mitigation process.
An inrush mitigation report is included with every product.
Aderis’ turnkey product and service offerings include the creation and delivery of audit event reporting for submission to utility and third party owners’ engineers.
FASTER INSTALLATION
Most customers receive, set, and terminate the ClearSky PLUS in a less than a day. ClearSky PLUS is 100% self-contained, completely pre-assembled, and self-powered. Just add the grid!
INTELLIGENT COMMISSIONING
Never wait for monitoring or SCADA again. Every ClearSky PLUS arrives with a browser-based Remote Interface that provides instant access to diagnostics, relay events, data logging, and remote configuration.
LOWER COST OF OWNERSHIP
Bucket trucks are expensive! ClearSky PLUS brings all interconnection equipment 30 feet down to ground level where it may be easily inspected, operated, and serviced.
100% PRE-AUTOMATED SWITCHING
The pre-insertion switching sequence is pre-programmed and coupled with the protective relay for fully-automated reclosing behaviors.
MONITOR REMOTELY
The pre-insertion controller can be monitored remotely using the Built-in User Interface powered by Aderis Energy’s powerful Acuity edge platform and via industry standard MODBUS TCP/IP.
INTUITIVE LOTO
Technicians can enable or disable automatic operation of the switching sequence by using the manual automatic / repair-service-mode switch.
