Climatronics - LED Digital Display Systems
Climatronics` LED Digital Displays combine high reliability, moderate cost, rugged construction, and large bright digits to meet the most demanding applications. These rack mountable displays utilize bright red- orange L.E.D. digits. Displays use a passive integration, dualslope, analog to digital conversion technique which provides excellent long-term stability, accuracy, linearity, noise rejection, and jitter-free performance. Standard features include differential and bipolar single-ended signal input, rugged glass filled Cycolac case and single edge, card type electrical connection to provide easy maintenance and replacement.
The displays use differential signal input which offers a particular advantage when used in high electrical noise environments or when noise is likely to be present on the signal input leads. Differential input has the effect of canceling this noise allowing the unit to display the true signal.
The required DC inputs are supplied by Climatronics` various signal conditioners.
Each display is factory labeled with type of parameter to be displayed and units of measure, both of which must be specified at the time of order.
- 3-1/2 & 4 Digit Configuration
- Rack Mountable
- Easy to Read Red-Orange L.E.D.
- Auto-Zero (No Zero Adjustment)
