CML Innovative Technologies Ltd
CML - Superflat Bezel with Resistor
Mechanical features - Lens typ: Flat; Lens size: 3 mm; Bezel typ: Superflat bezel; Screw thread size: M6; Bezel material: Metal; Connector type: Tab terminals 2,0mm x 0,5mm; Number of Connectors: 2; IP Code: IP40; Max. panel thickness: 8,5 mm.
Optical features
Indicator type
standard
Electrical features
Voltage tolerance
10 %
Pin assignment
Brass terminal = anode, tinned terminal = cathode
Thermal features
Operating temperature
-20...+60 °C
Storage temperature
-25...+80 °C
Norms & Standards
UL listed
Yes
