CML Innovative Technologies Ltd
CML - Superflat Bezel without Resistor
Mechanical features - Lens typ: Flat; Lens size: 3 mm; Bezel typ: Superflat bezel; Screw thread size: M6; Bezel material: Metal; Connector type: Leads of LEDs; Number of Connectors: 2; IP Code: IP40; Max. panel thickness: 8,5 mm.
Optical features
Indicator type
standard
Electrical features
DC current
20 mA
Pin assignment
Long pin = anode, short pin = cathode
Thermal features
Operating temperature
-20...+60 °C
Storage temperature
-25...+80 °C
