Hitachi High-Tech - Model CMI155 & CMI157 -Coating Thickness Handheld Gauges for PCB Copper
The CMl155 and CMl157 are capable of measuring the thickness of a single layer or the total thickness of applied coatings on steel, aluminium and other metals. The base of the probe is designed for measurement of smooth surfaces with an extended measurement range. These gauges are ideal metrology tools for: Paint & powder coaters. Coating inspectors. Automotive and aerospace finishers. Electroplating plants.
Most popular related searches
handheld thickness gauge
thickness monitoring
metrology system
coating thickness monitoring
metrology
PCB
automatic monitoring
Our compact, handheld gauges are factory calibrated. Just point and measure and the gauge will automatically select the best measurement technique dependent on the base material being evaluated. These gauges are durably designed with a rubberized protective cover designed to withstand use in harsh conditions.
- One touch, Easy Operation
- Factory calibrated.
- Automatic detection of substrate.
- Integrated probe.
- Casing IP52 rated, protects against dust and water.
- Body dimensions: mm: 110 (H) x 50 (W) x 25 (D) in: 4.3" (H) X 2" (W) X 1" (D).
- Weight: 90 g (3.2 oz).
- Batteries: 2 x AAA.
- Protective Case: IP52 rated
- Convex radius: 25 mm /1".
- Concave radius: 50 mm / 2",
- Clearance: 125 mm/5".
- Measurement area: 40 mm x 40 mm/ 1.6" x 1.6".
