Calplas - Model Ø 415 – 960 mm -Columns

SHARE

Laminated polyester reinforced with fibreglass column (GRP). Polyester casted threaded connections. Design according to needs (diffusers according to filtering media used, cylindrical height, connections, etc …). Designs according to filtering media used (Sand, activated carbon, AFM, etc...). Different chemical barriers according to needs (Ionic exchanger, anionic exchanger (ANION), cationic exchanger (CATION), softener, denitrification, etc...).

Most popular related searches

activated carbon

stainless steel pipe

cation exchanger

denitrification

Emptying plug PVC GAS threaded plug

Top lid Plasticized steel/PVC/Polypropylene top lid

Bottom lid Plasticized steel/PVC/Polypropylene bottom lid

Legs Polyester closed legs. Check anchorage system

Sight glass Methacrylate circular sight glass. Only provided as a standard in some models (Check data sheets)

Top distribution Top diffuser with PVC pipes. For other distributions, check "Other distributions" in options

Bottom distribution Polypropylene distribution with PVC pipes. Distribution according to requirements / media (Sand, active carbon, anionic resin, etc...)

Threaded connections Threaded connections: Polyester casted GAS threads. Ask for other standards (ANSI, JIS...)

Man hole Polyester casted manhole with plasticized steel lid. Transparent methacrylate lid available for pressures of 2.5 kg/cm². Manhole orientation according to needs. Only avialable for some models

Body Laminated polyester reinforced with fiberglass (GRP)
Top lid Plasticized steel / PVC / Polypropylene
Bottom lid Plasticized steel / PVC / Polypropylene
Connections Polyester reinforced with fiberglass threads or flanges
Design pressure 2.5 / 5 / 7 kg/cm²
Emptying plug
Side manhole (According to model)

Nozzle plate
GRP nozzle plate, built together with the end. KSH polypropylene nozzles. 0.2 or 0.5 mm slots

Other distributions
Distribution based on customer needs

Pipe support
Stainless steel pipe support

Anchorage system
Direct anchorage system to ground. Ask for other anchorage systems

Sight glass
GAS threaded methacrylate sight glass. Threads casted in polyester

Aditional connections
Aditional connections (flanges or threads) for filling, emptying, etc

Methacrylate top lid
Transparent methacrylate lid. Only for P = 2.5 kg/cm²

Cylindrical height
Customizable cylindrical height based on customers requests

High chemical resistance
Corrosion resistant chemical barrier based on customers needs. (ANION, CATION... )

Name plate support
Customizable measures based on customers requests

Front valve support
Stainless steel front valve support. Different measures available. Ask for more information

Polypropylene lids
Connections based on customers needs

PVC lids
Connections based on customer needs
