Comate - Model CAE350S -Air Compressor Analyzing System
CAE350S air compressor analyzing system help you to know your compressors better. Measure FAD flow on inlet pipe of compressor. Measure power consumption of the flow meter. Control the cost of compressed air via calculate power ration & energy intensity. Control compressor status via know the frequency of on/off loading time. Generate a brief report of all data above.
- Universal design, fit in inlet pipe from DN40~DN200(1.5’’`8’’)
- Flow meter installed on inlet pipe, easy to install, no need of pipe working
- One cell phone can read all data and set the system, very easy to operate
- Generate a report of all data and email to users automatic
- Protable & movable design, one free case provided to hold the whole system
CAE350S Air Compressor Analyzing System Composition
COMATE air compressor analyzing software to read and set the system
With the help of COMATE analyzing software users can directly read the real-time important statics on a PAD that installed COMATE APP. The APP can also generate an detailed report with curve diagram to help customer to understand the condition of the compressor better or even compare the tested compressor with another compress.
