ZOGLAB - Model NANO2-T -Compact temperature logger
NANO2 series upgraded compact PDF data logger is designed with the world leading semiconductor technology and featured design & craft by ZOGLAB. It creates amazing work by adding low temperature resistant LCD, rechargeable battery and auto PDF report without software operation into such a compact size logger. Newest NANO series, with the air transportation "Pass-card", will be the loyal security guard for your goods anytime and anywhere.Most popular related searches
- Sensor model Digital sensor/NTC
- T Measuring range -30℃~70℃，-40℃~85℃(No Display)
- T Measuring accuracy ±0.3℃(23℃±2℃)，±0.5℃(FS)
- T Resolution 0.1℃/0.2℉
- Memory size 60,000 units / 120,000 units; customization is supported
- Alarm Highlight LED indicator with dual colors
- Sampling interval 10s
- Logging interval 2s~24hrs
- Start with delay time 1s~120s
- Start mode Immediate start / Time-lapse start / Timing start / Magnetic start
- End mode Full / Timing end / Magnetic end
- Timing start/end Random start/End with format YYMMDD HHMMSS
- Interface USB2.0
- Battery 3.6V lithium battery (Rechargeable)
- Battery lifetime 45~150days (Working time)
- Recharge times ≥300 cycles
- IP Class IP64
- Storage temperature -50℃~90℃
- Software Quick Log
- Dimensions 79×22×7.4mm
- Weight 12g
- LCD display area 21×5mm
- Housing ABS+PC, flame-retardant, toxicity and halogen free
- Certificates CE, FCC, C-TICK, VCCI,CNAS Certification of Safe Air Transport
· Super compact size designed for cold chain; connect with PC via the integrated USB port directly
· Auto PDF report once connected with PC without software operation
· HD LCD shift displays the real-time T & RH data, history max & min value and over-limit alarm
· Suitable for cold chain transportation with the Certification of Safe Air Transport
· Super low power consumption, reusable application, huge memory capacity
