Great Wall - Model PYF -Compound Cone Crusher
PYF compound cone crusher is an updated and improved model that combines the characteristics of spring and hydraulic cone crushers. It is widely used in fields of mining, building materials, metallurgy,etc. It is suitable for medium and fine crushing on basalt, river pebbles, granite, quartz stone, metal ore and other high-hardness materials.
- Reasonable cavity type and stroke design make the material pass through the crushing cavity faster and the output is higher.
- Hydraulic cavity clearing and hydraulic adjustment of the discharge port improve the operating efficiency of the equipment.
- There is no need to inject glue for the assembly of the mantle and concave liners, and the replacement is quick and convenient.
- Automatic lubrication system to ensure the safety of equipment parts.
The motor drives the eccentric bushing to rotate through the pulley, V-belt, transmission shaft, and bevel gear. The main shaft would do pendulum movement under the force of eccentric sleeve, so that the mantle liner above the main shaft approaches and sometimes leaves the concave liner. Materials would be continuously extruded, squeezed and bent to be crushed in the annular crushing cavity formed by mantle and concave liners, the crushed materials are discharged from the bottom discharge port.
