Ro-Flo Compressors, LLC

- Model 2CC - Compressor

From

0

Inlet Connection 2' ANSI Class 150 Flat Face Flange.Outlet Connection 1.5' ANSI Class 150 Flat Face Flange.Operating Speed Range 865 rpm through 2200 rpm.Maximum Allowable Working Pressure 80 psig  (5.5 barg).Maximum Allowable Operating Temp 350°F  (176°C).Shaft Seal Single face mechanical or double bellows.Bearings Steel cage, Alloy steel rollers and races (no yellow metals).Lubrication Once through oil injection system - 5 points (by others).Drive Type Direct couple or belt driven, suitable for VFD.Shaft End 1.25' diameter at coupling
