MST - Concrete Silo for Manure and Liquid Storage
The MST Concrete Silo is a robust and versatile storage solution designed for the containment of manure, sludge, water, and other liquids. Manufactured with reinforced concrete, the silo boasts double reinforcement both vertically and horizontally, ensuring structural integrity under varying conditions. Available in a range of heights from 300 to 600 cm and diameters from 1000 to 3550 cm, the capacity ranges from 237 m³ to 5,883 m³. For additional security, the walls range from 16 cm to 18 cm in thickness. Installation involves connecting 150 cm wide elements with a specialized coupling, followed by pouring from above to ensure a seamless structure. Completing the assembly is a concrete floor fully anchored to the silo walls. The system supports various covers, such as floating or tension covers, and employs under-basin piping for efficient filling and emptying operations. The MST Concrete Silo meets all necessary standards and regulations and includes a permit application service.
A very solid concrete manure silo. The silo is not only suitable for manure, but also for sludge, water and other liquids.
The MST Concrete Silo is available in heights of 300, 400, 500 and 600 cm and with diameters from 1000 cm to 3550 cm. With this, the smallest volume is 237 m³ and the largest volume is 5,883 m³.
The MST Concrete Silo has walls that are fully double reinforced both vertically and horizontally.
Up to and including 500 cm height, the walls have a thickness of 16 cm and a thickness of 18 cm at 600 cm.
The elements are 150 cm wide and are connected to each other by a special coupling, after which they are poured from above. A concrete floor is then installed in the MST Concrete Silo that is completely anchored to the walls.
As a cover, a floating cover or a tension cover can be placed on the concrete manure silo.
The emptying and filling of the manure silo takes place via a remove/fill pipe underneath the basin.
WHY A MST-CONCRETE SILO:
- Proven quality since 1975
- All mixing options are easy to apply
- Easy and quick to install
- Solid construction due to thick floors and walls
- Meets all standards and regulations
- Permit application is provided by us as standard
- Built by our own professional staff
