ElvaX - Model PmX-5050 -Continuous Particulate Matter Monitoring System
PmX-5050 is a fully stand-alone device for continuous analysis of particulate matter (PM) elemental composition, intended for online elemental analysis of heavy metals in the ambient air. Particulate matter’s presence in the air and its overall accumulation in the environment are the subjects of growing public concern, especially in the manufacturing facilities, plants, and factories surrounding areas. It is vital to measure and assess the PM concentration in the air to prevent any possible harm to natural resources, people residing in such areas and overall environmental deterioration of the region.
Accuracy
With powerful hardware and comprehensive software algorithms, the ElvaX PmX-5050 offers the highest precision and accuracy of PM analysis for a wide range of elements.
Automation
Up to 3 months of stand-alone continuous analysis of PM 2.5 or PM 10 elemental concentration in ambient air.
Stability
Thanks to the automatic correction of ambient temperature, humidity and pressure influence, and automatic calibration adjustment, ElvaX PmX-5050 offers the highest long-term stability of the analysis
- Continuous analysis of PM 2.5 or PM 10 elemental concentration
- Full compliance with the US EPA IO-3.3 standard
- Up to 3 months of stand-alone continuous operation
- Automatic correction of ambient temperature, humidity and pressure influence
- Heated sampling stage for condensing prevention
- Simple calibration procedure and tape replacement
- Intuitive software interface
Previous solutions for PM monitoring were able to measure only overall PM presence and concentration, while full understanding of the PM impact on the human health and environment can only be reached based on elemental analysis.
General
- Applicable standard: USA EPA IO-3.3
- Flow rate: (0~20) L/min
- Filter tape: PTFE
- Tape replacement interval: up to 3 months
- Power supply: AC 100V~240V, 50/60 Hz
- Power consumption: 200 W
- Dimensions (w/o sampling inlet): 500mm * 500mm * 450mm
- Weight (w/o sampling inlet): 40 kg
- External connection: USB, Ethernet
XRF unit
- X-Ray tube: 50W, 50kV, 3mA
- Primary beam filter changer: 5 positions, automatic
- X-Ray detector: SDD
- Sampling and analysis times: 3 ~ 1440 min
- Measurement range: 0 ~ 200 µ g/m3
- Detection limit: 0.1 ng/m3 for most elements
- Calibration samples: SS316 for energy calibration, NIST 2783 for concentration calibration, other samples(optional)
Environmental Conditions
- Ambient temperature: 0 ° C ~ 40 ° C
- Humidity: 0 ~ 80%
- Altitude: up to 1000m
