COOLSPLIT - Model MSG 7 -Split Air-conditioning Units

This appliance, the SPLIT type, is a special air-conditioner where the heat conduction medium is a mixture of water and glycol. This enables the unit to cool at ambient  temperatures up to -10 °C. The internal unit is fitted with a rotating compressor, an expansion valve and a low pressure switch with automatic re-set function. It is also equipped with a high pressure switch, a water/refrigerant heat exchanger, a circulating water pump and a 5-stage fan. Other components include a defrosting thermostat, a thermostat for controlling room temperature, a condensate pump with tank and two level sensors (overflow control).
