Cryo Plants
Our cryogenic gas or turbo expander plants help improve project economics by delivering custom engineered solutions with competitive pricing to off-the-shelf designs (from contract to start-up). BCCK’s cryo plant solutions and proven process designs are specifically tailored for your specific project. As a result, our process will result in higher efficiencies, greater recoveries, and more operating flexibility across a wide range of inlet gas flow rates and concentrations than pre-engineered solutions.
In addition to custom designed turbo expander plants and the associated cryogenic gas advantages, BCCK also can offer custom designed results with a quicker delivery and lower costs by utilizing previous turbo expander plant designs for your project. Our previous cryogenic plant designs all process rich associated gas that would match almost any associated gas NGL extraction project. We can utilize near 100 percent of the previous design or make modifications per your specific requirements.
- 225 MMSCFD C2R-Flex
- 225 MMSCFD RSV
- 100 MMSCFD RSV
- 60 MMSCFD GSP
- 75 MMSCFD GSP
- 100 MMSCFD RSV
- 60 MMSCFD RSV
BCCK has developed a NGL extraction process that allows for maximum margins for the producer. If the recovered component of ethane is negative in value when sold as a liquid product as compared to the BTU value of ethane, then the producer will want to minimize the recovered ethane component while maximizing the propane and heavier components.
BCCK’s patented technology, C2R-Flex, will accomplish this. If the ethane component has a positive spread value when sold as liquid, then the producer will want to maximize the recovered ethane in the NGL liquid.
- High ethane recovery of 98% + ethane and near 100% of all heavier products
- Minimum ethane recovery of less than 5% and 98+ % for propane using auxiliary propane refrigeration
- Minimum ethane recovery of less than 5% and 98+ % for propane without using auxiliary propane refrigeration. Note that this option will require additional residue compression.
One significant advantage for C2R-Flex is that the operation mode between ethane recovery and ethane rejection can be accomplished quickly and without facility outage. This option will allow for frequent operational mode changes, if desired, assuring maximum profitability.
